The PUV-1730PL-AVLC Transmitter and Receiver Kit enables video resolutions up to 4K UHD including 10/12-bit HDR & Dolby Vision, to be transmitted along with HD audio, 2-Way IR, RS-232, PoH (Power over HDBaseT™) signals from a distance of 35m (4K60 4:4:4): 70m (4K60 4:2:0). This solution provides advanced signal management ensuring reliable results in the most demanding installation environments. All audio, video, control, and power are transmitted simultaneously over a single CAT6a/7 cable up to 70m. Using the OAR (Optical Audio Return) feature, audio can be sent from the display or local source back to the TX.
Despite the 10.2Gbps limitation of HDBaseT™ technology, this ground breaking product enables data rates of up to 18Gbps to be received using AVLC (Adaptive Visually Lossless Compression) Technology. The receiver enables 4KUHD sources up-to and including 4K@60Hz (4:4:4 8-bit) as well as 10/12 bit sources with HDR (Including Dolby Vision) to be received over distance from the transmitter. The result is a perfect 6G 4K visually lossless image delivered to the display screen.
