Type: AU-11CA

  • HDMI Audio Embedder with built in Repeater

The AU-11CA Audio Embedder lets you insert an external audio signal into any HDMI source. The device allows you to insert analogue or digital stereo and multi-channel digital surround sound signals (via Optical) to give users the capability to overcome audio issues within complex HDMI installation. The AU-11CA also repeats the HDMI signal to allow an extended total HDMI cable range.

  • Compliant with HDMI v1.3 , HDCP 1.2 and DVI 1.0
  • Supports Optical Sample Rate up to 96 kHz
  • Supports LPCM Stereo, DTS and Dolby Digital via Optical input
  • Supports up to 24bit resolution digital audio
  • Supports resolutions of 1080P up to cable lengths of 10m either side of the device
  • Supports HDMI Sample Rates up to 192 kHz
  • Supports 3D signals
  • Dimensions : 85mm [W] x 85mm [D] x 35mm [H]
